    Efficient Wire And Cable Accessories Pull Winding Machine High Speed

    Ask Lasest Price
    Brand Name : HERRMAN
    Model Number : NLY
    Payment Terms : L/C, D/A, D/P, T/T
    Delivery Time : 11 working days
    Price : USD 1 Kilogram
    Supply Ability : 50000 Kilogram/per month
    Certification : CE
    • Product Details
    • Company Profile

    Efficient Wire And Cable Accessories Pull Winding Machine High Speed

    Pull Winding Machine


    Pullwinding machine model ,

    Winding Double way

    NL-PW-100/8 PR 16NL-PW -200/16 OR 32NL-PW-400/32 OR 64 OR 128
    Max.Winding size(≤mm)100200400
    Total Winding Bobin NO.8or 1616or3232or 62or 128
    System Motor Power (KW)2.2/3.04.0/5.55.5/7.5/11
    Winding Rotary Speed (Cicle/min)0-250-25/0-200-20/0-15/0-10
    Roving of Bobbin weight (≤kg)25
    Tension force of winding (≤kg)0.02-0.2
    Machine controlTtansducer

    Angle of the pipe area

    Center to center of fiber(≤200mm

    60°-85°

    40°-80°

    70°-85°/60°-80° 50°-75°

    Join the Pulrtusion within the Close loop use encoder into PLC is possible


    Machine center (mm)920±20

    1000±20

    1200±20

    1000±20

    1200±30

    1500±40

    Exterior Machine size (L/W/H)2.0*1.5*2.0

    2.0*1.5*2.1

    2.4*1.8*2.3

    2.4*1.9*2.4

    2.4*2.2*2.6

    2.4*3.5*3.8
