3300lbs/1600~3000mm Electric Pallet Stacker
1.Technical Specification
Electric Pallet Stacker (Walkie type) HM CDDC |
| Characteristics | 1.1 | Model | | HM CDDC15-16 | HM CDDC15-30 |
| 1.3 | Power | | Electric | Electric |
| 1.4 | Operation mode | | Walkie Type | Walkie Type |
| 1.5 | Rated load capacity | Q(Kg) | 1000 | 1500 |
| 1.6 | Load center | C(mm) | 500 | 500 |
| 1.7 | Bearing Distance | X(mm) | 726 | 726 |
| 1.8 | Wheelbase | Y(mm) | 1197 | 1197 |
| Weight | 2.1 | Self-weight with battery | kg | 596 | 656 |
| 2.2 | Shaft load at full load, drive end/load end | kg | 743/1343 | 764/1392 |
| 2.3 | No-load shaft load, drive end/load end | kg | 433/163 | 477/179 |
| Wheels, Chassis | 3.1 | Wheel type front/rear | | PU | PU |
| 3.2 | Front Wheel | ∅×w(mm) | Φ80x70 | Φ80x70 |
| 3.3 | Rear wheel | ∅×w(mm) | Φ210x70 | Φ210x70 |
| 3.4 | Wheel track, front Wheel | b10(mm) | 515 | 515 |
| 3.5 | Rear Wheel Base | b11(mm) | 530 | 530 |
| Dimension | 4.1 | Mast Lowered Height | h1(mm) | 2055 | 1980 |
| 4.2 | Lift Height | h3(mm) | 1600 | 3000 |
| 4.3 | Max. HeightWhen Lifting | h4(mm) | 2075 | 3478 |
| 4.4 | Fork Clearencewhen Mast Lowered | h13(mm) | 85 | 85 |
| 4.5 | Overall Length | l2(mm) | 1858 | 1865 |
| 4.6 | Overall Width | b1(mm) | 800 | 800 |
| 4.7 | Fork Size | s/e/l(mm) | 65/165/1150 | 65/165/1150 |
| 4.8 | Fork Spread | b5(mm) | 350-680 | 350-680 |
| 4.9 | Min. Ground Clearence | m2(mm) | 25 | 25 |
| 4.10 | Stacking channel width, pallet 1000×1200 (1200 placed across forks) | Ast(mm) | 2238 | 2238 |
| 4.11 | Min. Turning Radius | Wa(mm) | 1380 | 1380 |
| Performance | 5.1 | Max. Travel Speed(Unload/Load) | km/h | 4/3.5 | 4/3.5 |
| 5.2 | Lifting Speed(Unload/Load) | m/s | 0.101/0.09 | 0.101/0.09 |
| 5.3 | Decnet Speed(Unload/Load) | m/s | 0.111/0.130 | 0.111/0.130 |
| 5.8 | Max. gradeability, no load/full load | ％ | 6/3 | 6/3 |
| 5.1 | Brake Type | | Electromagnetic | Electromagnetic |
| Motor | 6.1 | Driving Motor | kw | 0.75 | 0.75 |
| 6.2 | Lifting Motor | kw | 2.2 | 2.2 |
| 6.3 | Battery | | Lead Acid | Lead Acid |
| 6.4 | Battery Vol./Capacity | V/Ah | 2x12/80 | 2x12/80 |
| 6.5 | Charger | V/A | 24V/10A | 24V/10A |
| Other | 7.1 | Control Model | | DC | DC |
| 7.2 | The noise level in the driver's ear is based on EN12053 | dB(A) | 75 | 75 |
2. Description
The Stacker have adjustable fork widths intended to cater all sorts
of items and loads which makes it ideal for handling materials
around warehouses, storerooms, loading and unloading trucks,
loading docks and manufacturing floors.
It is constructed out of fully-welded steel with superior pumps and
parts ensuring maximum longevity and durability despite daily heavy
and rough usage. The Stacker has also a decent turning radius of
1380Wa(mm) which works well on congested or tight areas.
3.PACKING&SHOPING
4.PRODUCTION SCENE
5.FAQ
Q1: Can Herrman provide customized products? OEM products or ODM
products?
A1: Yes, Herrman can provide customized products according to your
requirement. Both OEM and ODM are acceptable. We do a lot
ofnon-standard products, welcome your special custom-made.
Q2: What's the specification of the chargers?
A2: Herrman have all kinds of the chargers and welcome the
customers to custom-made.
Q3: How about the delivery time?
A3: Usually Herrman producing time is 15-20 working days after we
receive the advanced payment. For some standard products, we have
most in stock and could delivery immediately.
Q4: Can we print the LOGO on products?
A4: Yes, the OEM is available with the permission of our customers.
Q5: What is your payment term?
A5: T/T,L/C or O/A if you want any other way, please contact us.And
accepted Payment Type: L/C,D/P D/A,MoneyGram,Credit
Card,PayPal,Western Union,Cash,Escrow;
Q6: What can I get from cooperating with Herrman?
A6: 1). Unique products, with customized service.
2). Timely production and delivery, time is money.
3). Market protection service, long term business strategy.
Q7:how can we guarantee quality?
A7:1).Always a pre-production sample before mass production.
2).Always final Inspection before shipment.
Q8: what services can we provide?
A8:1).Accepted Delivery Terms:
FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express
Delivery,DAF,DES；
2).Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
3).Language
Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
